ROCKWOOL

产品图片：ROCKWOOL（官方）。

ROCKWOOL · Sandwich panel core

ROCKWOOL Conrock

0.042 W/m·K
Thermal conductivity λ: Euroclass A1
Reaction to fire (EN 13501-1): 1 kg/m²
Water absorption

索取报价数据表（PDF） ↗

由 World Steel 随您的钢结构建筑一并供应或单独供应 – 一份订单、一次发运、一个合作伙伴。

概览

关于Conrock

Conrock L is specially designed for use as insulation core for metal faced composite panels. Conrock L range is the ideal core insulation for metal faced sandwich panels used in commercial, industrial and public buildings in various applications such as external wall, roof, partition, etc. Conrock L have excellent compressive, tensile and shear strength to bear system gravity load and wind load. It can contribute to prevent fire from spreading in case of fire and provide protection for saving lives and reducing property losses. Conrock L is not easy to expand or shrink, and its stable thermal insulation performance enables the building to achieve the purpose of thermal insulation and energy saving.

Application: ROCKWOOL Conrock® provides an excellent structural core for factory engineered flat and profiled sandwich panels. It is suitable for outdoor and indoor applications such as facades, walls, roofs, partitions, ceilings and heavy loaded sandwich panels for e.g. extra wide spans or application of greater height.

主要优势

ROCKWOOL Conrock core is non-combustible and it is rated A1 in accordance with European Fire Class
EN13501-1.
No CFCs, HFCs, HCFCs, or asbestos are used in the manufacture of ROCKWOOL Conrock.
Lightweight and easy to handle.
Supplied as pre-cut lamella or slabs.

World Steel · 建筑围护材料中心

我们如何在钢结构建筑中使用Conrock

ROCKWOOL Conrock is the non-combustible core of metal-faced sandwich panels – the choice when a steel building needs fire-safe wall, roof or partition panels. World Steel supplies stone-wool-core panels with the steel structure, matched to the girts, purlins and fire design of the building.
