WS modular homes

WS 2B Suite

A one-module bedroom wing – two bedrooms with a shared bathroom core and no kitchen – to combine with a living module for family and courtyard homes.

Australie / NZÉtats-UnisEurope

Demander un devis Caractéristiques

  • 54 m² · 1 module
  • Two bedrooms, bathroom core
  • Galvanised Q355 steel frame
  • Factory-built bathroom pod and MEP rough-in
  • Up to ≈ 91 % completed in the factory
  • Base, Fire-rated (FRL 60/60/60 target) or custom

The home

The bedroom module of the WS range: two generous bedrooms with their own glazed doors to the deck and a shared bathroom core between them. Combine it with a living module to make a family home, or repeat it for guest rooms, eco-lodges and student housing.

WS 2B Suite floor plan
WS 2B Suite – bedroom 01, fixed bathroom core and bedroom 02.

What is built in the factory

  • Steel frame – galvanised Q355 frame engineered for strength, precision and durability, with corner posts for lifting and stacking.
  • Wet core – factory-built bathroom pod for quality and consistency.
  • MEP rough-in – services pre-installed for fast connection on site.
  • External envelope – high-performance thermal and weather protection.
  • Interior fit-out – finishes designed for comfort and function.
  • Dispatch ready – inspected, wrapped and ready for safe transport.

Every WS model shares the same module system – frame, floor, walls, roof, wet core and services – so specifications, approvals and spare parts stay consistent across a project.

Variants

Choose WS-ML-01 Base for standard residential or accommodation use, WS-ML-02 Fire-rated where enhanced fire performance is required, or a project-custom build-up – see the variant table on the module system page.

Normes et exigences par marché

Les codes selon lesquels World Steel conçoit, fabrique et documente ce produit – et les principales exigences géométriques et de charge sur chaque marché.

Australie / NZ

  • NCC 2022 Vol. 1 & 2Building Code of Australia – Class 1a / 2 / 3 as applicable
  • AS/NZS 1170Structural design actions incl. wind regions
  • AS 4100 · AS/NZS 4600Steel and cold-formed steel structures
  • AS 1530.4Fire-resistance tests – FRL
  • AS 3740Waterproofing of domestic wet areas
  • AS/NZS 3000 · AS/NZS 3500Electrical installations · plumbing and drainage
Fire-rated variant
FRL 60/60/60 target with tested or assessed systems
Approval
Building certifier per state; transport permits per route
Toutes les normes Australia & New Zealand →

États-Unis

  • IBC / IRCInternational Building / Residential Code
  • ICC/MBI 1200 & 1205Off-site construction: planning, inspection, regulatory compliance
  • ASCE 7 · AISC 360Loads and steel design
  • NEC · IPCElectrical and plumbing codes
Approval
State modular / industrialised building program where applicable
Toutes les normes United States →

Europe

  • EN 1990 – EN 1993Eurocodes – basis, actions, steel
  • EN 13501-2Fire resistance classification (REI)
  • EN 1090-2 Certifié WSCExecution of steel structures – WS EXC3
Approval
National building rules and energy performance per country
Toutes les normes Europe →

Synthèse fournie à titre indicatif – le cahier des charges du projet, l'édition du code adoptée et l'autorité compétente prévalent.

Finitions

FinitionNormes / remarques
ExteriorInsulated wall panel with charcoal frame trim; cladding options to suit
DeckTimber or composite deck to project
InteriorLining and paint, vinyl plank flooring, cabinetry and joinery
Project finishesColours, fixtures and fittings on request

Questions fréquentes

How long does production take?

Typically 4–6 weeks of factory production per batch after design approval, while foundations and site works proceed in parallel.

How much is finished in the factory?

Up to about 91 % of the work – frame, envelope, wet core, services and finishes. On site the modules are set on footings and connected to services.

Can the layout or finishes be changed?

Yes – finishes, fixtures, window positions and the build-up can be tailored as a project-custom variant.
