ROCKWOOL Curtainrock®

ROCKWOOL CURTAINROCK® is a stone wool insulation board designed for a variety of curtain wall systems i.e. Perimeter Fire Containment System and Through-Penetration Firestop System.

0.037 W/m·K
Thermal conductivity λ: Euroclass A1
Reaction to fire (EN 13501-1): 1 kg/m²
Water absorption

SIRIM
UL Classified

Request a quotation Data sheet (PDF) ↗

Supplied by World Steel with your steel building or on its own – one order, one shipment, one partner.

Overview

About Curtainrock®

Curtainrock is a lightweight, semirigid stone wool insulation board designed to provide enhanced fire protection in curtain wall and perimeter fire cotnainment systems. These products are non combustible and fire resistand and will not develop smoke or promote flame spread when exposed to fire.

Application: Mainly applied on Curtain wall insulations , external walls on commercial buildings and high rise and multiple storey buildings. It is the ideal material of choice for curtain wall system applications, either as the backpan of curtain wall or as a fire safing and smoke seal at gaps.

Key benefits

Contributes to excellent fire performance for curtain wall system and provides up to 2 hours fire rating
Lightweight semirigid insulation stone wool board designed to provide enhanced fire protection in curtain wall and perimeter fire containment systems.
Non - combustible
Flexible, tested and used in conjunction with othermajor fire-stopping products as a perimeter fire sealing system
Can be used for floor slab without upstand beam construction
Can be installed at site or prefabricated in the factory. Ease of installation with various installation options

World Steel · building envelope hub

How we use Curtainrock® in steel buildings

In World Steel buildings ROCKWOOL Curtainrock® insulates façades, curtain walls, partitions and party walls – adding fire safety and acoustic comfort to offices, hotels, schools and mixed-use steel frames. We coordinate thickness and fixings with the cladding and wall framing and deliver it with the steel package.

01Specified with the structure – thickness, density and facing matched to the roof, wall and fire design.
02Quantities taken from the same 3D model as the steel, purlins and cladding.
03Packed and shipped with the steel package – one delivery schedule to site.

Applications

Where Curtainrock® is used

External Wall Insulation › Unitized Curtain Wall
Passive Fire Protection › Fire Penetration

Technical data

Curtainrock® – technical properties

Thermal conductivity

Property	Unit	Value
Thermal conductivity	W/m·K	0.037

Technical properties

Property	Unit	Value
Reaction to Fire	Euroclass	A1
Water Absorption	kg/m2	1
Water Vapour Absorption	%	0.04

Values as published by the manufacturer for this market. Always check the current data sheet and the approvals required for your project before ordering. Manufacturer page ↗

Approvals & labels

Listed approvals for Curtainrock®

SIRIMProduct certification by SIRIM QAS International, Malaysia.

UL ClassifiedClassified by UL Solutions for the properties shown in the UL listing.

Approvals as shown by the manufacturer for this product. Certificates and listings apply to the tested product and system – request the current copies with your quotation.
