- M8 – M64 and ¼ – 4 in
- A193 B7, A307, F1554, ISO 898-1 classes
- DIN 976 / ISO 4.6 – 10.9
- Stainless A2-70 / A4-80
- Cut to length, chamfered ends
- Double-end studs for anchors and flanges
Uses
Threaded rods hang services, tie bracing, anchor equipment and form the rods of chemical and cast-in anchors. Stud bolts – threaded at both ends with a plain centre – are used for anchor rods and flanged connections.
Range
| Standard | Grade | Typical use |
|---|---|---|
| ASTM A307 | Grade A / B | Hangers, light anchors |
| ASTM F1554 | 36 / 55 / 105 | Anchor rods |
| ASTM A193 | B7 | High-strength studs, flanges |
| ISO 898-1 / DIN 976 | 4.6, 5.6, 8.8, 10.9 | Metric rods and anchors |
| ISO 3506 | A2-70, A4-80 | Corrosive and coastal environments |
Standards and requirements by market
Codes World Steel designs, fabricates and documents this product to – and the key geometric and load requirements in each market.
Summary for orientation only – the project specification, the adopted code edition and the authority having jurisdiction govern.
Finishes
| Finish | Standards / notes |
|---|---|
| Hot-dip galvanized | ASTM F2329 · ISO 10684 · AS/NZS 1214 – nuts tapped oversize and lubricated |
| Zinc plated | ISO 4042 |
| Stainless | A2-70 / A4-80 |
