- 3070 doors, 18 gauge
- 161, mortise or panic-reinforced preps
- 16 ga 5¾ in masonry frames, LH or RH
- Labelled up to 3 hours
- 20 doors / 40 frames per pallet
- Interchangeable with WS HM frames
What it is
Most buildings repeat the same opening again and again. The fast-pack range covers that standard opening – a 3'0" × 7'0" door in 18 gauge steel with a matching 16 gauge masonry frame – prime painted and packed on pallets so it can be ordered by the pallet and delivered quickly.
Fast-pack frames are built to the same profile as WS hollow metal frames, so they can be mixed on one project: standard openings from stock, special openings made to order.
The range
| Item | Description | Preparation | Pallet |
|---|---|---|---|
| Door 3070 – 18 ga | Polystyrene core, steel top cap, 16 ga channels | 161 cylindrical lock | 20 doors |
| Door 3070 – 18 ga | Panic-reinforced blank door | Exit device | 20 doors |
| Door 3070 – 18 ga | Mortise edge | Mortise lock | 20 doors |
| Frame 5¾ in – 16 ga | Masonry, knock-down, mitred corners, base anchor | ASA strike, RH | 40 frames |
| Frame 5¾ in – 16 ga | Masonry, knock-down, mitred corners, base anchor | ASA strike, LH | 40 frames |
Specification
- Door: 18 gauge steel, polystyrene core, 16 gauge inverted top and bottom channels
- Fire rating: labelled up to 3 hours for door and frame
- Closer reinforcement: 14 gauge, standard
- Frame: 16 gauge, 5¾ in masonry depth, knock-down, precision mitred corners
- Hinge preparation: reinforced, standard commercial hinge locations
- Finish: gray primer
Standards and requirements by market
Codes World Steel designs, fabricates and documents this product to – and the key geometric and load requirements in each market.
United States
- ANSI/SDI A250.8Standard steel doors and frames (SDI-100)
- ANSI/SDI A250.6Hardware reinforcings on steel doors and frames
- ANSI/DHI A115 seriesHardware preparation in steel doors and frames
- ASTM A653 / A924Galvannealed steel sheet A40 / A60
- NFPA 80 · UL 10CFire doors – installation and positive-pressure fire test
- Fire label
- 20 min to 3 h on a labelled door and frame
- Accessibility
- ADA / ICC A117.1 – threshold rise ≤ ½ in
Australia / NZ
- AS 1905.1Fire-resistant doorsets
- AS 1530.4Fire-resistance tests of elements
- NCC Volume OneEgress, fire separation and access
- AS 1428.1Design for access – door circulation and hardware
- Fire doorset
- door, frame and hardware tested as one assembly
Europe
- EN 14351-1Windows and external pedestrian doorsets – CE marking
- EN 16034Fire and smoke resisting doorsets – CE marking
- EN 1634-1Fire resistance test for doorsets
- EN 1192Doors – classification of strength requirements
- CE marking
- Declaration of performance for each doorset type
Summary for orientation only – the project specification, the adopted code edition and the authority having jurisdiction govern.
Finishes
| Finish | Standards / notes |
|---|---|
| Prime coat | Baked-on rust-inhibitive primer to ANSI A250.10 – primer gray standard |
| Factory colours | Light gray, bronze, true white, bright white, off white |
Frequently asked questions
Can I mix fast-pack frames with made-to-order doors?
Yes. The frame profile and hinge locations match the WS hollow metal range, so stock and special openings can be combined on one project.
